HCPL-6231 Images
- Manufacturer: Avago Technologies (Broadcom)
- Category: Isolators~Optoisolators - Logic Output Package/Case: 20-CLCC
- Description: OPTOISO 1.5KV PUSH PULL 20LCCC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HCPL-6231 Specifications:
- MfrPart.: HCPL-6231
- Mfr: Broadcom Limited (Avago Technologies)
- Description: OPTOISO 1.5KV PUSH PULL 20LCCC
- Product Category: Isolators~Optoisolators - Logic Output
- Package: Bulk
- Series: -
- PartStatus: Active
- NumberofChannels: 2
- Inputs-Side1/Side2: 2/0
- Voltage-Isolation: 1500VDC
- CommonModeTransientImmunity(Min): 1kV/µs
- InputType: DC
- OutputType: Push-Pull, Totem Pole
- Current-Output/Channel: 15 mA
- DataRate: 5MBd
- PropagationDelaytpLH/tpHL(Max): 350ns, 350ns
- Rise/FallTime(Typ): 45ns, 10ns
- Voltage-Forward(Vf)(Typ): 1.3V
- Current-DCForward(If)(Max): 8mA
- Voltage-Supply: 4.5V ~ 20V
- OperatingTemperature: -55°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 20-CLCC
- HCPL-6231 AVAGO (Broadcom), OPTOISO 1.5KV PUSH PULL 20LCCC, Isolators~Optoisolators - Logic Output
HCPL-6231, AVAGO authentic parts in stock from AVAGO (Broadcom) authorized distributors, order today, can ship immediately.
