HCPL-2630-520 Images
- Manufacturer: Avago Technologies (Broadcom)
- Category: Isolators~Optoisolators - Logic Output Package/Case: 8-SMD, Gull Wing
- Description: OPTOCOUPLER 10MBD UL+T/R
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
HCPL-2630-520 Specifications:
- MfrPart.: HCPL-2630-520
- Mfr: Broadcom Limited (Avago Technologies)
- Description: OPTOCOUPLER 10MBD UL+T/R
- Product Category: Isolators~Optoisolators - Logic Output
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Discontinued at
- NumberofChannels: 2
- Inputs-Side1/Side2: 2/0
- Voltage-Isolation: 5000Vrms
- CommonModeTransientImmunity(Min): 5kV/µs
- InputType: DC
- OutputType: Open Collector, Schottky Clamped
- Current-Output/Channel: 50 mA
- DataRate: 10MBd
- PropagationDelaytpLH/tpHL(Max): 75ns, 75ns
- Rise/FallTime(Typ): 24ns, 10ns
- Voltage-Forward(Vf)(Typ): 1.5V
- Current-DCForward(If)(Max): 15mA
- Voltage-Supply: 4.5V ~ 5.5V
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- Package/Case: 8-SMD, Gull Wing
- HCPL-2630-520 AVAGO (Broadcom), OPTOCOUPLER 10MBD UL+T/R, Isolators~Optoisolators - Logic Output
