ACPL-W346-560E Images
- Manufacturer: Avago Technologies (Broadcom)
- Category: Isolators~Isolators - Gate Drivers Package/Case: 6-SOIC (0.268, 6.80mm Width)
- Description: OPTOISO 5KV 1CH GATE DRIVER 6SO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ACPL-W346-560E Specifications:
- MfrPart.: ACPL-W346-560E
- Mfr: Broadcom Limited (Avago Technologies)
- Description: OPTOISO 5KV 1CH GATE DRIVER 6SO
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- Technology: Optical Coupling
- NumberofChannels: 1
- Voltage-Isolation: 5000Vrms
- CommonModeTransientImmunity(Min): 50kV/µs
- PropagationDelaytpLH/tpHL(Max): 120ns, 120ns
- PulseWidthDistortion(Max): 50ns
- Rise/FallTime(Typ): 8ns, 8ns
- Current-OutputHighLow: 2A, 2A
- Current-PeakOutput: 2.5A
- Voltage-Forward(Vf)(Typ): 1.55V
- Current-DCForward(If)(Max): 25 mA
- Voltage-OutputSupply: 10V ~ 20V
- OperatingTemperature: -40°C ~ 105°C
- MountingType: Surface Mount
- Package/Case: 6-SOIC (0.268, 6.80mm Width)
- ACPL-W346-560E AVAGO (Broadcom), OPTOISO 5KV 1CH GATE DRIVER 6SO, Isolators~Isolators - Gate Drivers
