ACPL-K49T-060E Images
- Manufacturer: Avago Technologies (Broadcom)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 8-SOIC (0.268, 6.81mm Width)
- Description: OPTOISOLATOR 5KV TRANSISTOR
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ACPL-K49T-060E Specifications:
- MfrPart.: ACPL-K49T-060E
- Mfr: Broadcom Limited (Avago Technologies)
- Description: OPTOISOLATOR 5KV TRANSISTOR
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Tube
- Series: -
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 5000Vrms
- CurrentTransferRatio(Min): 32% @ 10mA
- CurrentTransferRatio(Max): 100% @ 10mA
- TurnOn/TurnOffTime(Typ): 20µs, 20µs (Max)
- Rise/FallTime(Typ): -
- InputType: DC
- OutputType: Transistor
- Voltage-Output(Max): 20V
- Current-Output/Channel: 8mA
- Voltage-Forward(Vf)(Typ): 1.5V
- Current-DCForward(If)(Max): 20 mA
- VceSaturation(Max): -
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.268, 6.81mm Width)
- ACPL-K49T-060E AVAGO (Broadcom), OPTOISOLATOR 5KV TRANSISTOR, Isolators~Optoisolators - Transistor, Photovoltaic Output
ACPL-K49T-060E, AVAGO authentic parts in stock from AVAGO (Broadcom) authorized distributors, order today, can ship immediately.
